Amtrol 399635 WX-251 Well Tank 62 Gallon

Product Description

The AMTROL 399635 WX-251 is a diaphragm well tank with a vertical stand. It features a 1-1/4 inch male threaded inlet/outlet connection and a 62-gallon tank capacity. Constructed from Tuf-Kote HG blue steel with an antimicrobial inner lining, it is suitable for residential well water systems, both indoors and outdoors.

• Antimicrobial liner neutralizes bacteria on contact.
• DuraBase composite stand never corrodes.
• Heavy duty butyl diaphragm provides extra strength and flexibility.

Product Highlights

This well tank has a high-strength steel shell and a stainless steel system connection. It meets NSF/ANSI 61, IAPMO, NAF, and ISO 9001 standards.

Product Information

Standard Information

• Brand: AMTROL
• Manufacturer Part Number: 399635
• Country of Origin: USA

Technical Specifications

• Manufacturer Part Number: 399635
• Manufacturer Name: Amtrol
• Manufacturer Part Number Additional: WX-251
• Series/Model: WX-200
• Type: Vertical Stand
• Tank Capacity: 62 Gallon
• Tank Material: Tuf-Kote HG Blue Steel
• Tank Inner Lining: Antimicrobial
• Temperature Rating: 200 Deg F
• Pressure Rating: 150 PSIG
• Precharge Pressure: 38 PSIG
• Diaphragm Material: Heavy Duty Butyl
• Inlet Outlet Connection: 1-1/4 Inch Male Threaded
• Inclusions Features: Projection Welded Air Valve, Turbulator Water Circulator, High Strength Steel Shell, Stainless Steel System Connection, Positive Diaphragm Seal
• Application: Residential Well Water System, Indoor/Outdoor
• Applicable Standard: NSF/ANSI 61, IAPMO, NAF, ISO 9001
• Additional Information: Lead-Free; Maximum Acceptance Factor 0.55; Stand Diameter 20-1/2 Inch
• UPC: 642031644770
• UNSPSC Code: 24111810
• Product UPC: 642031644770
• Product Category: PLUMBING
• Shape: Round
• Height: 47 in
• Material: Steel
• Mounting Type: Stand
• Connection Size: 1-1/4 in
• Connection Type: MNPT
• Outside Diameter: 22 in
• Maximum Temperature Rating: +200 deg F
• Weight: 87.00
• Gallons: 62 Gallons
• Diameter: 22"
