Ametek 132508 Process Pressure Gauge 0-30 Psi 6 Inch

Product Description

The AMETEK 132508 is an analog process pressure gauge designed for accurate pressure monitoring in industrial and commercial piping systems. It features a 6-inch dial with a 0 to 30 psi range and delivers 0.5% of scale accuracy, making it suitable for applications that demand reliable, readable measurements. The thermoplastic case resists corrosion and impact, while brass wetted parts provide compatibility with a wide range of process media. Connection is via a 1/2-inch NPT lower-mount fitting for direct inline installation. This gauge is installed by licensed plumbers, pipefitters, HVAC technicians, and industrial maintenance professionals.

The AMETEK 132508 is suited for residential and light commercial plumbing, HVAC hydronic systems, compressed air lines, and general process piping where a non-liquid-filled analog gauge is appropriate. The 6-inch dial face provides clear readability from a distance, which is practical in mechanical rooms and utility spaces. The lower-mount NPT connection allows installation directly into a pipe tee, manifold, or process port without additional adapters in most standard configurations.

Key Features

• 0 to 30 psi pressure range with 0.5% of scale accuracy
• 6-inch analog dial for high-visibility readings at a distance
• 1/2-inch NPT lower-mount connection for direct inline installation
• Brass wetted parts for broad media compatibility
• Thermoplastic case construction for corrosion and impact resistance
• Non-liquid-filled design suitable for stable, vibration-free installations

Compatibility

Designed as an OEM-style process pressure gauge for use in standard 1/2-inch NPT lower-mount ports on plumbing, HVAC hydronic, compressed air, and general industrial process piping systems.

Installation Notes

Installation should be performed by a licensed plumber, pipefitter, or qualified HVAC technician. Shut off and depressurize the system fully before removing an existing gauge or installing this unit. Apply thread sealant or PTFE tape to the NPT threads per local plumbing code requirements. Do not over-tighten the connection; use a wrench on the hex fitting, not on the dial case, to avoid damaging the gauge internals.
