American Standard A5AC3036B1000A Split System Ac 3 Ton

Product Description

The AMERICAN STANDARD A5AC3036B1000A is a 3-ton single-phase split system air conditioner designed for residential and light commercial cooling applications. This condensing unit pairs with a compatible indoor coil or air handler to deliver whole-structure cooling as part of a ducted split system. Licensed HVAC technicians install and commission this type of equipment, which requires proper refrigerant handling certification under EPA Section 608. The unit is rated for single-phase power, making it suitable for standard residential electrical service configurations.

This condensing unit is intended for split system cooling installations where a matched indoor evaporator coil and air handler are already in place or being installed simultaneously. At 3 tons of nominal cooling capacity, it is sized for medium-footprint residential structures or smaller commercial spaces. It is engineered for outdoor installation and connects to the indoor section via refrigerant line sets.

Key Features

• 3-ton nominal cooling capacity suited for medium residential or light commercial loads
• Single-phase electrical configuration compatible with standard residential service
• Split system design requires a matched indoor coil or air handler
• Outdoor condensing unit intended for permanent installation on a level pad or mounting surface

Compatibility

Designed as an OEM-style outdoor condensing unit for use in residential and light commercial split system cooling configurations requiring a matched indoor evaporator coil or air handler.

Installation Notes

Installation must be performed by a licensed HVAC technician holding EPA Section 608 certification for refrigerant handling. Disconnect and lock out all electrical power before servicing or connecting the unit. The condensing unit should be mounted on a solid, level pad with adequate clearance on all sides per manufacturer and local code requirements. Follow all applicable local mechanical and electrical codes during installation and commissioning.

Technical Specifications

• Nominal Cooling Capacity: 3 tons
• System Type: Split system air conditioner
• Phase: Single phase

Standard Information

• Brand: AMERICAN STANDARD
• Manufacturer Part Number: A5AC3036B1000A
