American Standard 3453.001.020 Wht El Bowl

Product Description

The AMERICAN STANDARD 3453.001.020 Wht El Bowl is a floor-mounted Madera Back Spud Elongated Toilet Bowl that operates between 1.1 and 1.6 gpf. When used with a high-efficiency flush valve, it meets high-efficiency toilet standards. The EverClean surface helps maintain the cleanliness of the toilet bowl. It has been factory flush tested.

• Floor-mount, elongated flushometer bowl, less seat
• High Efficiency Toilet (HET) operates in the range of 1.1 gpf – 1.6 gpf (4.2 Lpf – 6.0 Lpf)
• Maximum Performance (MaP) score of 1,000 grams at 1.1 - 1.6 gpf

Product Highlights

This toilet bowl features a permanent EverClean surface, a standard 15" rim height, and a 2-1/8" fully-glazed trapway.

Product Information

Standard Information

• Brand: AMERICAN STANDARD
• Manufacturer Part Number: 3453.001.020

Technical Specifications

• Color: White
• Material: Porcelain
• Brand: American Standard
• Installation Method: Floor Mounted
• Shape: Oval
• Overall Height: 15" (bottom of the base to the highest point on the toilet)
• Overall Length: 28-1/4" (back of bowl fixture to front of rim)
• Overall Width: 14" (furthest point left to furthest point right)
• Rough-In: 10" - 12" (wall behind toilet to center of waste outlet in floor)
• Trapway Size: 2-1/8" (diameter of the outlet for water/waste exiting the bowl)
• Water Area: 10 x 12
• Bowl Height: 15 in.
• Depth: 28.25 in.
• Height: 15 in.
• Rough In: 10 in.
• Spud Size: 1.5 in.
• Trapway: 2.125 in.
• Width: 14 in.
• Bowl Shape: Elongated
• Configuration: Bowl Only
• Flush Type: Siphon Jet
• Spud Placement: Rear
• Theme: Traditional
• Flush Technology: HET High Efficiency
• ADA: No
• Approved for Commercial Use: Yes
• Collection: Madera, Everclean
• Series: Madera
• WaterSense Certified: No
