ALPSCONTROLS TR75VA005 Transformer

Product Description

The ALPSCONTROLS TR75VA005 is a control transformer that provides a capacity of seventy-five VA. It is designed to convert several input voltages including one hundred twenty, two hundred eight, two hundred forty, and four hundred eighty VAC to a twenty-four VAC output. This transformer allows for flexible installation with foot and single threaded hub mounting options. It includes a built-in circuit breaker for overcurrent protection, enhancing safety in operation. The transformer meets Class 2 UL5085-3 Listing, and is C-UL, CE, and RoHS compliant.

• Capacity of seventy-five VA meets various voltage conversion needs.
• Supports input voltages of four hundred eighty, two hundred forty, two hundred eight, and one hundred twenty VAC.
• Includes circuit breaker for added safety and reliability.

Product Highlights

Designed for voltage conversion in various environments, this transformer is suitable for HVAC systems, industrial control circuits, and more.

Product Information

Standard Information

• Brand: ALPSCONTROLS
• Country of Origin: China

Technical Specifications

• VA Rating: 75 VA
• Input Voltage: 120/208/240/480 VAC
• Output Voltage: 24 VAC
• Mounting: Foot and Single Threaded Hub Mount
• Over Current Protection: Circuit Breaker
• Wire Length: 9.5 inches
• Frequency: 50/60 Hz
• Operating Temperature: -30 to 140° F
• Approvals: Class 2 UL5085-3 Listed, C-UL, CE, RoHS
