Aloris CXA-8 Threading Tool Holder 13-18 Inch Lathe

Product Description

The ALORIS CXA-8 is a threading tool holder designed for use with CXA-series quick-change tool post systems on engine lathes. It accommodates lathe swings from 13 to 18 inches, making it suited to mid-size manual lathes commonly found in job shops and maintenance facilities. The holder stands 2 inches overall height with a centerline height of 1-1/8 inches, providing consistent, repeatable tool positioning for threading operations. Licensed machinists and tool and die technicians install this holder as part of a quick-change setup to reduce tool changeover time and maintain precise center height without re-indicating between passes.

The CXA-8 is intended for threading operations on lathes with a 13 to 18 inch swing capacity. It mounts to any compatible CXA-series quick-change tool post. This holder is appropriate for both production threading and general-purpose single-point thread cutting in manual lathe environments. It does not include through-coolant capability, making it best suited for dry or flood-coolant-from-external-source applications.

Key Features

• CXA series quick-change tool post compatibility for fast, repeatable tool swaps
• Designed for threading operations on 13 to 18 inch swing lathes
• 2 inch overall height with 1-1/8 inch centerline height for accurate tool positioning
• No through-coolant port - suited for external flood or dry cutting conditions
• Compact, rigid construction for stable threading passes

Compatibility

Designed for use with CXA-series quick-change tool post systems on engine lathes with a swing range of 13 to 18 inches.

Installation Notes

Installation is performed by a machinist or toolroom technician familiar with quick-change tool post systems. Before mounting or adjusting any tool holder, disengage the lathe drive and ensure the spindle is fully stopped. Set the tool holder in the quick-change post and lock it securely before verifying centerline height with a center gauge or reference point. Confirm the tool bit is clamped firmly and positioned correctly for the thread form before beginning any cutting operation.
