Allied Air 1.913019 BCE7E24MA4X-50 2 Ton R-410A TXV Air Handler (Multi-Position)

Product Description

Allied Air 1.913019 is a BCE7E24MA4X-50 series 2 ton R-410A air handler featuring a constant torque blower motor and a multi-position aluminum cabinet designed for low air leakage. The unit includes a thermostatic expansion valve (TXV), a 20 x 20 x 1 inch filter size, and line connections sized 3/8 inch liquid and 3/4 inch suction. Electrical rating is 208/230 V, single phase.

• Constant torque blower motor for consistent airflow and lower operating load compared to single-speed motors
• Sealed aluminum cabinet with less than 2% air leakage and anti-microbial infused drain pans to inhibit mold and bacteria
• Multi-position configuration with TXV, compatible with R-410A refrigerant; filter size 20 x 20 x 1 in and 208/230 V single-phase input

Product Highlights

2 ton R-410A multi-position air handler with constant torque blower, TXV, sealed aluminum cabinet, and anti-microbial drain pans.

Product Information

Standard Information

• Brand: ALLIED AIR
• Manufacturer Part Number: 1.913019

Technical Specifications

• Brand: Allied Air
• Manufacturer: Allied Air Enterprises
• MPN: 1.913019
• Model: BCE7E24MA4X-50
• Series: BCE7
• Nominal Capacity: 2 ton
• Refrigerant: R-410A
• TXV: Yes
• Configuration: Multi-Position
• Blower Motor Type: Constant torque
• Filter Size: 20 x 20 x 1 in
• Liquid Line Size: 3/8 in
• Suction Line Size: 3/4 in
• Input Voltage: 208/230 V, 1 phase
• Cabinet Material: Aluminum
• Cabinet Air Leakage: <2% air leakage
• Anti-microbial Protection: Drain pans infused with antibacterial agent
• UPC: 662551528350
• APR Part Number: 1854685
