Product Description
The ALL-SOURCE 95107 Carbon Monoxide Gas Detector is effective for ensuring safety where carbon monoxide detection is necessary. It is suitable for environments like laboratories and parking garages. This detector features two alarm relays that enable connection to external signaling systems. It provides visual alarms with LEDs and a four to twenty milliampere analog output.
- Two alarm relays for versatile signaling.
- Continuous monitoring with a diffusion gas sampling method.
- Optional RS-485 Modbus communication output.
Product Highlights
This detector is built for real-time monitoring and safety in harsh environments.
Product Information
Standard Information
-
Brand: ALL-SOURCE
-
MPN: 95107
Technical Specifications
-
Gases Detected: Carbon Monoxide (CO), Ethyl Alcohol (C2H5OH), Hydrogen Sulfide (H2S), Isopropyl Alcohol (IPA), Methyl Alcohol (MeOH)
-
Sampling Method: Diffusion
-
Range: 0-100% ppm
-
Accuracy: ± 10% of Reading
-
Operating Temperature: -40 to +50 °C
-
Display: 68 x 128 pix LCD Displays 30-min Trend, Bargraph & 0.6 inch Concentration Data
-
Sensor Type: Disposable Electrochemical or LEL Catalytic Bead
-
Sensor Life: 2 to 5 years under Normal Conditions
-
Signal Outputs: 4-20 mA analog output
-
Power Requirements: 24 VDC
-
Power Consumption: 95 mA
-
Width: 5.12 inches
-
Height: 5.0 inches
-
Depth: 8.0 inches
-
Weight: 4.7 lbs
-
Enclosure: Stainless Steel
-
Optional Extras: Alarm Output: 3 Alarm Relays for Low and High-Level Gas Alarm and System Fault, Signal Output: RS-485 Modbus Digital Communications
