Mrcool A-12-HP-C-230D-O Advantage 5th Gen 12k BTU 230V Condenser

Product Description

The MRCOOL A-12-HP-C-230D-O Advantage 5th Gen 12k BTU 230V Condenser is designed for practical and effective heating and cooling. This system utilizes eco-friendly R-454B refrigerant and features a DC inverter for energy efficiency. The Gold Fin condenser resists corrosion, making it suitable for coastal environments. A WiFi Smart Kit enables control via Amazon Alexa and Google Assistant.

• Eco-friendly R454B refrigerant
• AHRI certification
• DC inverter for energy efficiency

Product Highlights

This MRCOOL condenser provides efficient, quiet, and convenient comfort, perfect for spaces up to 500 sq. ft. It offers smart home integration and corrosion resistance for lasting performance.

Product Information

Standard Information

• Brand: MRCOOL
• Manufacturer Part Number: A-12-HP-C-230D-O

Technical Specifications

• Brand: MRCOOL
• MPN: A-12-HP-C-230D-O
• UPC: 840255586832
• Category 1: Mini-Split
• Model: A-12-HP-230D-O
• Configuration: Wall Mounted
• Bundle Avg Coverage Area: 500 - 600 Sq Ft
• Bundle Cooling Capacity: 1 Ton
• Bundle Cooling Efficiency (SEER2): 21.3
• Heat Pump Efficiency (HSPF2): 7
• Series: Advantage
• Zones: 1
• Popular Applications: Game Room, Garage, Guest Room, Man Cave, Server Room, Sunroom
• Region Compatibility: Nationwide
• Product Height (in): 21.85
• Product Length (in): 11.93
• Compressor: Inverter
• Product Width (in): 30.12
• Cooling Capacity: 12000 BTU/H
• Electrical Phase: 1-Phase
• Line Set Connection Type: Flared
• Liquid Line Size: 1/4 inch
• Max Overcurrent Protection: 25 amps
• Refrigerant: R-454b
• Suction Line Size: 5/8 inch
• System Application Type: Ductless Split Systems
• Voltage: 208V-230V
• Warranty: 1 Year Parts, 2 Year Compressor
• Air Flow Direction: Horizontal
• Blower Motor: Variable Speed
• Heating Capacity: 12000 BTU/H
• Highest Decibel Rating: 54 dB-A
• Maximum Amperage: 15 Amp
• Room Size: 550 Sq Ft
