Advanced Distributor Products tac61d 5 Ton Cased N-coil Txv R-410A

Product Description

The ADVANCED DISTRIBUTOR PRODUCTS tac61d is a 5-ton cased N-coil designed for split-system residential and light commercial air conditioning installations. Rated at 61,000 BTU/h, this aluminum coil uses a TXV metering device for precise refrigerant flow control and is charged for R-410A systems. The multi-position configuration allows installation in upflow, downflow, or horizontal orientations, giving installers flexibility to match a range of air handler or furnace configurations. Licensed HVAC technicians typically handle installation as part of a matched split system or equipment changeout.

This coil fits into forced-air cooling systems where a cased N-coil is the preferred form factor. The 26-inch width suits standard residential air handler cabinets. Multi-position capability makes it a practical choice when the equipment orientation is not fixed at the time of ordering or when serving multiple job types. It is intended for use with R-410A refrigerant systems and should be paired with a compatible outdoor condensing unit to achieve rated efficiency.

Key Features

• 61,000 BTU/h cooling capacity at 5-ton rating
• TXV metering device for accurate refrigerant management across varying load conditions
• Cased N-Coil design for structural protection and clean installation
• Multi-position configuration supports upflow, downflow, and horizontal installs
• Aluminum construction for corrosion resistance and efficient heat transfer
• Compatible with R-410A refrigerant systems

Compatibility

Designed as an OEM-style replacement or new-install evaporator coil for 5-ton R-410A split-system air conditioning and heat pump applications requiring a cased N-coil with TXV metering.

Installation Notes

Installation should be performed by a licensed HVAC technician holding an EPA Section 608 certification for handling refrigerants. Disconnect and lock out all electrical power and shut off refrigerant supply before opening the system. Verify the coil orientation matches the air handler configuration before securing the cabinet. Leak-test all brazed and flare connections before recharging the system.

Technical Specifications

• BTU Rating: 61,000 BTU/h
• Tonnage: 5.0 Ton
• Coil Type: Cased N-Coil
• Configuration: Multi-Position
• Metering Device: TXV
• Refrigerant Type: R-410A
• Material: Aluminum
• Width: 26 inches

Standard Information

• Brand: ADVANCED DISTRIBUTOR PRODUCTS
• Manufacturer Part Number: tac61d
