Accurate Bushing MFYR-80 Flanged Yoke Roller 80mm

Product Description

The ACCURATE BUSHING MFYR-80 is a flanged yoke roller designed for cam follower and track roller applications in industrial machinery. Built from carbon steel, this roller provides reliable load-bearing performance in linear and curved track systems. The 80 mm roller diameter, 44 mm roller width, and 63,500 N dynamic load capacity make it suited for moderate-to-heavy radial load conditions. The flanged design keeps the roller aligned on the track, reducing lateral drift during operation. Millwrights, maintenance technicians, and mechanical assemblers typically install this style of roller in conveyor systems, jigs, fixtures, and material handling equipment.

This flanged yoke roller fits into applications where a stud-type or yoke-mount cam follower is required to run along a flat or grooved track surface. The 25 mm bore accommodates a shaft or pin mount in a yoke-style carrier. With a flange diameter of 102 mm and flange thickness of 13.5 mm, it provides positive lateral guidance without requiring additional retention hardware. Typical install environments include industrial conveyors, cam-actuated mechanisms, press tooling, and assembly line fixtures in both light manufacturing and heavy industrial settings.

Key Features

• 80 mm roller diameter for stable contact and load distribution on track surfaces
• 63,500 N dynamic load capacity handles moderate-to-heavy radial loads
• Flanged design provides built-in lateral guidance on track systems
• Carbon steel construction delivers durability in industrial environments
• 25 mm bore fits standard shaft and pin sizing for yoke-mount assemblies
• 102 mm flange diameter with 13.5 mm flange thickness for positive track retention

Compatibility

Designed as a direct-fit flanged yoke roller for industrial cam follower and track roller applications requiring an 80 mm roller diameter, 25 mm bore, and yoke-style mounting.

Installation Notes

Installation is typically performed by a millwright or mechanical maintenance technician. De-energize and lock out all associated machinery before removing or installing roller components per OSHA lockout/tagout procedures. Verify bore fit and shaft or pin clearance before pressing or bolting the roller into the yoke carrier. Do not exceed the rated dynamic load capacity during operation, and inspect the roller and track surface for wear during scheduled maintenance intervals.
