Accurate Bushing MFCR-30 Flanged Cam Follower

Product Description

The ACCURATE BUSHING MFCR-30 is a flanged cam follower designed for use in linear motion, conveyor, and cam-driven mechanical systems. It features a 30 mm roller diameter, a 12 mm stud diameter, and a 14 mm stud length, making it a compact stud-type roller bearing suited for track and rail applications. The roller is constructed from carbon steel, providing reliable hardness and wear resistance under load. With a static load capacity of 1,000 pounds, this cam follower handles demanding industrial duty cycles. Millwrights, maintenance mechanics, and machine builders typically specify this component for automated machinery and material handling equipment.

The MFCR-30 is used in industrial and commercial machinery where a flanged roller is required to maintain precise tracking along a cam surface, guide rail, or linear track. The flanged design helps prevent lateral displacement, keeping the roller properly seated during operation. It is suited for fabrication equipment, packaging machinery, printing equipment, and similar cam-actuated or track-guided assemblies where a small-diameter, high-load stud roller is needed.

Key Features

• 30 mm roller diameter for compact fitment in tight mechanical assemblies
• 12 mm stud diameter provides a secure threaded or press-fit mounting point
• 40 mm flange diameter aids lateral guidance and prevents track misalignment
• 5.0 mm flange thickness for added structural support at the roller edge
• Carbon steel roller construction delivers hardness and wear resistance
• 1,000 lb static load capacity suitable for demanding industrial applications

Compatibility

Designed as an OEM-style replacement or direct-fit cam follower for industrial machinery requiring a flanged stud-type roller with a 30 mm roller diameter and 12 mm stud diameter.

Installation Notes

Installation is typically performed by a millwright or mechanical maintenance technician. De-energize and lock out all power and motion sources before removing or installing any cam follower. Verify that the mating stud bore or mounting hole matches the 12 mm stud diameter before installation. Do not exceed the rated static load capacity, and inspect the cam track or guide rail surface for wear or damage before fitting the new roller.
