Accurate Bushing MCRV-85-S Sealed Stud Cam Follower

Product Description

The ACCURATE BUSHING MCRV-85-S is a sealed stud-type cam follower designed for demanding linear and rotary motion applications. Built from carbon steel, this cam follower features an 85mm roller diameter and a 35mm roller width, providing a broad contact surface for load distribution. The 30mm stud diameter with a 100mm overall length and 63mm stud length gives it a robust mounting profile. It is rated for a dynamic load capacity of 60,000 N and a static load capacity of 142,000 N. The sealed design keeps lubrication in and contaminants out, extending service life in dirty or high-cycle environments. Industrial maintenance technicians and mechanical engineers typically install this component in conveyor systems, cam mechanisms, and track-guided assemblies.

This cam follower is suited for use in industrial machinery where a stud-mounted rolling element is needed to follow a cam surface or travel along a track. The sealed construction makes it appropriate for applications with limited relubrication access or exposure to chips, dust, and coolant. The M30x1.5 metric thread and 32mm thread length allow secure engagement in standard threaded bores, making it a practical replacement or upgrade component in existing machine designs.

Key Features

• 85mm roller diameter with 35mm roller width for broad load contact
• Dynamic load capacity of 60,000 N and static load capacity of 142,000 N
• Carbon steel construction for durability in industrial environments
• Sealed bearing retains grease and excludes contaminants
• M30x1.5 metric thread with 32mm thread engagement length
• 100mm overall length with 30mm stud diameter for rigid mounting

Compatibility

Designed as an OEM-style replacement or direct-fit cam follower for industrial machinery requiring an 85mm roller diameter sealed stud cam follower with M30x1.5 thread specification.

Installation Notes

Installation is typically performed by industrial maintenance technicians or mechanical assemblers familiar with rolling element bearing components. The machine or conveyor system should be fully de-energized and locked out before replacing any cam follower. Use appropriate metric tooling to torque the stud into its threaded bore; consult the equipment manufacturer's service documentation for mounting specifications. Verify that the roller tracks freely and that the sealed element seats flush against the mounting surface before returning the machine to service.
