Accurate Bushing MCRV-22-SB Sealed Stud Cam Follower

Product Description

The ACCURATE BUSHING MCRV-22-SB is a sealed stud-type cam follower built on a full-complement needle roller bearing. It features a 22mm cylindrical steel roller, an M10 x 1 threaded stud with hex head, and a sealed closure to retain lubrication and exclude contamination. The static load capacity is 12,900 N, making it suited for moderate-to-heavy track and cam applications. The full-complement needle roller design maximizes load area within the compact envelope. Maintenance technicians and mechanical assemblers working on linear motion, indexing, and cam-driven machinery are the primary installers of this component.

The MCRV-22-SB is used in industrial machinery where a rolling contact element rides along a cam or track surface. Typical applications include conveyor systems, packaging equipment, printing machinery, automated assembly lines, and other cam-driven or linear-guide mechanisms. The sealed design suits environments where periodic re-lubrication is impractical or where light contamination is present. It is appropriate for both light industrial and heavier production equipment requiring a compact, stud-mounted roller follower.

Key Features

• Full-complement needle roller bearing for high radial load capacity in a compact envelope
• Sealed closure retains lubricant and resists contamination ingress
• 22mm cylindrical steel roller provides consistent contact along cam or track surfaces
• Hex-head stud design allows standard wrench installation and precise torque control
• M10 x 1 stud thread for direct mounting into tapped bores
• Rated to 6,000 RPM maximum, suitable for moderate-speed cam and follower applications

Compatibility

Designed as an OEM-style replacement or direct-fit cam follower for industrial machinery applications requiring a sealed stud-type needle roller follower with a 22mm cylindrical roller and M10 x 1 thread.

Installation Notes

Installation is performed by millwrights, maintenance mechanics, or mechanical assembly technicians. Before servicing, de-energize and lock out all power and motion sources on the machine per applicable LOTO procedures. Thread the stud into the tapped bore using a standard wrench on the hex head, and verify alignment of the roller face with the cam or track surface before final tightening. Do not exceed rated load or RPM values in service.
