Accurate Bushing MCR-90-S Sealed Stud Cam Follower

Product Description

The ACCURATE BUSHING MCR-90-S is a sealed stud-type cam follower designed for demanding industrial and mechanical applications. Built from carbon steel, this cam follower features a 90mm roller diameter and a 35mm roller width, offering a substantial contact surface for high-load tracking and guiding tasks. The 30mm stud diameter and 63mm stud length provide a secure, stable mounting interface, while the M30x1.5 thread with a 32mm thread length ensures a precise and rigid connection. The sealed design protects internal components from contamination, extending service life in dirty or high-cycle environments. The overall assembly length is 100mm.

The MCR-90-S is suited for use in conveyor systems, cam-driven mechanisms, linear guideways, and automated machinery where a reliable stud-mount roller is required. Its dynamic load capacity of 45,000 N and static load capacity of 85,000 N make it appropriate for medium-to-heavy load profiles in both industrial OEM builds and maintenance replacement scenarios. Licensed millwrights, machine technicians, and industrial maintenance professionals are the primary installers for this type of component.

Key Features

• 90mm roller diameter with 35mm roller width for a wide, stable contact surface
• Carbon steel construction for high strength and durability under load
• Sealed design prevents contamination ingress and reduces relubrication intervals
• 45,000 N dynamic load capacity and 85,000 N static load capacity
• M30x1.5 threaded stud with 32mm thread length for secure, precise mounting
• 100mm overall assembly length with 30mm stud diameter

Compatibility

Designed as an OEM-style replacement or direct-fit cam follower for industrial machinery requiring a sealed stud-type roller with a 90mm roller diameter and M30x1.5 stud thread specification.

Installation Notes

Installation should be performed by a qualified millwright or mechanical technician familiar with bearing and cam follower service procedures. Isolate and de-energize all associated machinery before beginning work, and verify that the mounting bore and thread engagement meet the specified M30x1.5 thread standard. Do not exceed the rated dynamic or static load capacities during assembly or operation. Consult applicable machinery OEM documentation and relevant industry standards for torque and preload requirements specific to the host machine.
