Accurate Bushing BCR-2-3/4-X Stud Cam Follower

Product Description

The ACCURATE BUSHING BCR-2-3/4-X is a sealed, self-lubricating stud cam follower designed for use in mechanical motion control and power transmission applications. It features a 2-3/4 inch roller diameter and 1-1/2 inch width, riding on a nonmetallic bushing that eliminates the need for external lubrication during service intervals. The stud measures 1 inch in diameter with an overall stud length of 2-1/4 inches, a thread length of 1-1/8 inches, and a 1-14 thread specification. The overall assembled length is 3-3/4 inches. Carbon steel construction provides durability under load. Maintenance technicians and millwrights install this type of follower in conveyor systems, cam-driven assemblies, and linear guide tracks.

This cam follower is suited for industrial mechanical assemblies where a sealed, maintenance-reduced bearing solution is required. Typical applications include conveyor lines, indexing machinery, packaging equipment, and cam-and-follower drive systems in both light and medium-duty industrial environments. The nonmetallic bushing allows operation in conditions where grease lubrication may be difficult to maintain or where contamination of grease is a concern. The sealed design helps protect the rolling surface from dust and debris in plant environments.

Key Features

• 2-3/4 inch roller diameter for load distribution across cam and track surfaces
• 1-1/2 inch roller width provides stable contact in linear and rotary cam applications
• Sealed design keeps contaminants out and retains internal lubrication
• Self-lubricating nonmetallic bushing reduces maintenance intervals
• Carbon steel construction for durability under mechanical load
• 1-14 threaded stud with 1-1/8 inch thread length for secure mounting

Compatibility

Designed as an OEM-style replacement or direct-fit stud cam follower for industrial mechanical assemblies requiring a 1 inch stud diameter, 1-14 thread, and 2-3/4 inch roller diameter configuration.

Installation Notes

Installation is performed by millwrights or maintenance mechanics familiar with cam-and-follower drive systems. De-energize and lock out all power to the machine before removing or installing any cam follower components. Use appropriate thread engagement depth per the equipment manufacturer's torque and fastener specifications. Inspect the mating cam surface or track for wear before installing a replacement follower.
