Accupro 713-MG Single Point Tool Bit Offset Threading

Product Description

The ACCUPRO 713-MG is a single point tool bit designed for offset threading and V-grooving operations on metalworking lathes and turning centers. Built with a micrograin solid carbide tip, this right-hand cutting tool delivers consistent edge integrity during threading passes, including threading to a shoulder. The shank measures 5/8 inches wide by 5/8 inches tall, with an overall length of 4 inches. It conforms to industry standard ER-10 and carries a 60-degree included angle, making it suited for standard V-thread profiles. Machinists and CNC lathe operators use this bit for production threading work where carbide grade consistency matters.

This tool bit is used in manual and CNC lathe applications requiring right-hand offset threading. The offset configuration allows the tool to cut threads close to a shoulder or step, reducing clearance issues common with straight-style tool bits. The ER tool bit style and ER-10 industry standard designation make this a recognized fit for threading and V-grooving setups in job shops, production facilities, and maintenance machining environments. It is sold individually and ships at a package quantity of one.

Key Features

• Micrograin solid carbide tip for consistent cutting-edge performance during threading passes
• Offset threading style enables threading to a shoulder with reduced clearance constraints
• 60-degree included angle compatible with standard V-thread profiles
• Right-hand cutting direction for conventional lathe threading operations
• ER-10 industry standard designation for recognized toolholder compatibility
• 5/8 inch square shank fits standard lathe tool posts and holders for this shank size

Compatibility

Designed as an OEM-style single point threading tool bit for use in lathe tool posts and holders accepting a 5/8 inch square shank, conforming to ER-10 industry standard specifications.

Installation Notes

Installation is performed by qualified machinists following standard lathe tooling setup procedures. The machine spindle must be stopped and the lathe powered down before seating or adjusting the tool bit in the tool post. Secure the shank firmly in the holder to the tool post manufacturer's specified clamping procedure before initiating any cut. Verify tool height and alignment to centerline before threading operations begin.
