Accupro 35372 Corner Chamfer End Mill 0.5in 4 Flute

Product Description

The ACCUPRO 35372 is a corner chamfer end mill designed for milling chamfers and angled edge profiles on metal and engineered materials. Built from powdered metal with a bright, uncoated finish, the 35372 runs a 0.5-inch diameter with a 4-inch overall length and a 2-inch length of cut. The 4-flute, right-hand cutting geometry with a 30-degree helix delivers efficient chip evacuation and smooth surface finishes in a range of ferrous and non-ferrous applications. The centercutting design allows plunge entry, adding flexibility to the tool path.

This corner chamfer end mill is suited for use on manual mills and CNC machining centers in general metalworking, tool and die, and maintenance machining environments. It handles chamfering, edge breaking, and angled profile work on steel, cast iron, aluminum, and similar workpiece materials. The 0.5-inch shank diameter fits standard R8, CAT, BT, and straight-bore toolholders commonly found in job shop and production settings. Fine pitch and right-hand flute direction make it a practical choice for finish chamfer passes.

Key Features

• Powdered metal construction for consistent hardness and wear resistance
• 4-flute, right-hand cut with 30-degree helix for smooth chip flow
• Centercutting design allows direct plunge entry
• Bright, uncoated finish suitable for general-purpose metalworking
• Fine pitch geometry for controlled edge chamfering and profile work
• 0.5-inch shank diameter fits standard toolholders

Compatibility

Designed as a general-purpose replacement or stocked corner chamfer end mill for manual mills and CNC machining centers accepting a 0.5-inch straight shank.

Installation Notes

Installation should be performed by a qualified machinist or tooling technician. Ensure the machine spindle is fully stopped and locked out before changing tooling. Seat the shank fully into the toolholder and torque set screws or collet nuts to the toolholder manufacturer specification. Inspect the cutting edges for chips or damage before each use.
