Accupro 35317 Corner Chamfer End Mill 0.5in 4 Flute

Product Description

The ACCUPRO 35317 is a corner chamfer end mill designed for machining chamfered edges and beveled profiles in metal workpieces. Built from powdered metal and left in a bright, uncoated finish, it delivers solid wear resistance for general-purpose milling operations. The 4-flute, right-hand cutting geometry provides efficient chip evacuation and a stable cut. With a 0.5-inch cutting diameter, a 3-inch length of cut, and a 5-inch overall length, this end mill suits applications requiring moderate reach without sacrificing rigidity. It is centercutting, allowing plunge entry directly into the material.

This end mill is suited for use in vertical machining centers, CNC mills, and manual knee mills across job shops, maintenance facilities, and production environments. The 30-degree helix angle and coarse pitch promote smooth cutting action in steel, cast iron, and similar ferrous materials. With a 0.5-inch shank diameter, it mounts directly into standard ER or end mill holders. Machinists and tool-and-die professionals handling chamfering, deburring, and edge-breaking operations will find this tool a straightforward, no-coating workhorse for everyday cuts.

Key Features

• Corner chamfer geometry for producing beveled edges and chamfered profiles
• Powdered metal construction provides consistent hardness and wear resistance
• 4-flute, right-hand cut with right-hand flute direction for stable chip flow
• Centercutting design allows direct plunge entry without a pre-drilled hole
• 30-degree helix angle reduces cutting forces and improves surface finish
• Bright, uncoated finish suited for general ferrous and non-ferrous applications

Compatibility

Designed as a standard-shank replacement-style corner chamfer end mill compatible with 0.5-inch end mill holders, ER collet chucks, and similar toolholding systems used on CNC and manual milling machines.

Installation Notes

Installation is performed by a machinist or toolroom professional. Ensure the spindle is fully stopped and the machine is powered down before changing tooling. Seat the 0.5-inch shank fully into the holder and torque the retention mechanism per the toolholder manufacturer's specifications. Inspect the cutting edges for chips or damage before each use, and confirm runout is within acceptable limits before engaging the workpiece.
