Accupro 35304 Corner Chamfer End Mill 0.625 in 4 Flute Tialn

Product Description

The ACCUPRO 35304 is a corner chamfer end mill designed for milling chamfered edges and angled profiles on metal workpieces. Built from powdered metal and finished with a TiAlN coating, it delivers heat resistance and extended tool life in demanding cutting applications. The 4-flute geometry supports efficient chip evacuation while maintaining surface finish quality. With a 0.625 inch cutting diameter and a 1.625 inch length of cut, it handles moderate-depth passes in ferrous and non-ferrous materials. This tool is installed and operated by machinists and CNC operators in job shop, production, and maintenance machining environments.

The 35304 is suited for chamfering, edge-breaking, and angled profile milling on steel, cast iron, and similar materials. Its centercutting capability allows plunge entry, giving operators flexibility in toolpath programming. The 30-degree helix angle balances cutting forces and chip flow across the four flutes. At 3.75 inches overall length with a 0.625 inch shank diameter, it fits standard ER and straight-bore tool holders used on vertical machining centers and manual mills alike.

Key Features

• TiAlN coating improves heat resistance and extends tool life in high-speed cutting
• Powdered metal substrate provides uniform hardness and wear resistance
• 4-flute design supports smooth surface finish and efficient chip removal
• Centercutting geometry allows direct plunge entry without a pilot hole
• 30-degree right-hand helix with right-hand cutting direction
• Coarse pitch flute spacing reduces cutting forces in tougher materials

Compatibility

Designed as an OEM-style replacement or standard tooling option for use in vertical machining centers, CNC mills, and manual milling machines accepting a 0.625 inch straight shank tool holder.

Installation Notes

Installation is performed by a qualified machinist or CNC operator. Ensure the spindle is fully powered down and the machine is in a safe lockout state before changing tooling. Seat the shank fully in the tool holder and torque the retention mechanism per the tool holder manufacturer specification. Verify runout with a dial indicator before beginning a production run to prevent premature tool wear or part rejection.
