Accupro 35296 Corner Chamfer End Mill 1.25in 6 Flute

Product Description

The ACCUPRO 35296 is a 6-flute corner chamfer end mill designed for precision milling operations in ferrous and non-ferrous materials. Built from powdered metal, it offers a 1.25-inch cutting diameter and a 2-inch length of cut (LOC), making it well-suited for chamfering, profiling, and finishing passes where a sharp, consistent corner break is required. The bright/uncoated finish is retained for applications where coating is unnecessary or where base material performance is preferred. At 4.5 inches overall length (OAL) and a 1.25-inch shank diameter, this tool is engineered for rigid tool holding in standard milling setups.

This end mill is used in machine shops, production environments, and job-floor applications where corner chamfering and edge preparation are part of the workflow. The coarse pitch, right-hand cut, and right-hand flute direction make it a standard-configuration tool appropriate for CNC machining centers and manual knee mills running conventional or climb milling passes. Its centercutting design allows plunge entry, adding versatility for operators who need direct entry into a workpiece without a pre-drilled start hole.

Key Features

• Powdered metal construction for improved wear resistance over standard HSS
• 6-flute geometry delivers a finer finish and higher feed rates on stable setups
• Centercutting design allows plunge milling capability
• Coarse pitch with right-hand cut and right-hand flute direction
• Bright/uncoated finish suitable for a wide range of base material applications
• 1.25-inch shank diameter for secure clamping in standard collet and end mill holders

Compatibility

Designed as an OEM-style replacement or direct-use corner chamfer end mill compatible with standard 1.25-inch bore end mill holders and collet chucks used in CNC and manual milling machines.

Installation Notes

Installation should be performed by a qualified machinist or toolroom professional. Ensure the machine spindle is fully stopped and the tool holder is clean and free of debris before seating the end mill. Verify runout with a dial indicator after installation to confirm proper seating. Follow the machine manufacturer torque recommendations for set screws or collet nuts and consult applicable shop safety standards before engaging the spindle.
