Accupro 33062 Corner Chamfer End Mill 4 Flute

Product Description

The ACCUPRO 33062 is a corner chamfer end mill designed for precision milling operations where a chamfered edge profile is required. Built from powdered metal, this tool offers consistent hardness and wear resistance suited for demanding cutting conditions. It features a 0.75-inch cutting diameter, a 1.625-inch length of cut, and a 4-flute configuration that promotes efficient chip evacuation and a smooth surface finish. The bright/uncoated finish makes it easy to inspect for wear during service intervals. This end mill is center-cutting, allowing it to plunge directly into material as well as perform peripheral cutting passes.

The 33062 is used in vertical machining centers and manual knee mills for chamfering, deburring, and profiling operations on ferrous and non-ferrous workpieces. With a 3/4-inch shank diameter and 3.75-inch overall length, it seats securely in standard end mill holders and collet chucks. A 30-degree helix angle balances cutting efficiency with tool stability across a range of materials. The right-hand cutting and right-hand flute direction suit conventional milling setups commonly found in precision machine shops and production environments.

Key Features

• Corner chamfer geometry for accurate edge profiling and deburring
• Powdered metal construction for consistent hardness and extended tool life
• 4-flute design promotes chip evacuation and improved surface finish
• Center-cutting capability allows direct plunge entry into workpiece material
• 30-degree helix angle balances chip flow and lateral cutting forces
• Bright/uncoated finish simplifies wear inspection during use

Compatibility

Designed as a direct-fit replacement for standard 3/4-inch shank corner chamfer end mill applications in vertical machining centers and manual milling machines using ER or end mill holder tooling systems.

Installation Notes

Installation should be performed by a qualified machinist or tooling technician. Ensure the spindle is fully stopped and the machine is powered down before changing tooling. Seat the shank fully into the holder and torque the retention hardware according to the toolholder manufacturer specifications. Confirm runout with a dial indicator before beginning a cut, and verify speeds and feeds against the material and tool manufacturer recommendations.
