Accupro 2500102 Chamfer Mill 3/4in 4 Flute 90 Deg Ticn Carbide

Product Description

The ACCUPRO 2500102 is a solid carbide chamfer mill designed for precision chamfering operations on ferrous and non-ferrous materials. Built with a 90-degree included angle and four flutes, it cuts a clean, repeatable bevel in a single pass. The TiCN coating adds surface hardness and lubricity, extending tool life in demanding applications. The cutter head diameter and shank diameter are both 3/4 inches, with an overall length of 4 inches. This tool is intended for use in CNC machining centers and manual mills where consistent chamfer geometry is required. Machinists and toolroom professionals are the primary users.

The 2500102 is suited for chamfering drilled hole entries, deburring sharp edges, and preparing mating surfaces on steel, stainless, cast iron, and aluminum workpieces. Its right-hand cutting direction and single-end configuration make it a standard choice for general-purpose chamfering in job shops, production machining, and tool-and-die environments. The 3/4-inch shank accepts standard ER or end mill holders commonly found in vertical machining centers.

Key Features

• 90-degree included angle for standard chamfer and countersink geometry
• Solid carbide construction for rigidity and wear resistance over high-speed steel alternatives
• TiCN coating improves hardness and reduces friction at the cutting edge
• 4-flute design balances chip evacuation and surface finish
• Right-hand cut, single-end configuration for straightforward setup
• Matching 3/4-inch cutter head and shank diameters simplify tool holder selection

Compatibility

Designed as a direct-fit replacement for standard 3/4-inch shank chamfer mills used in CNC and manual milling applications requiring a 90-degree chamfer geometry.

Installation Notes

A licensed machinist or qualified toolroom technician should install and qualify this tool before production use. Secure the 3/4-inch shank in a properly sized end mill holder or collet chuck and verify runout with a dial indicator before cutting. Power down the spindle completely before changing tooling. Follow the machine tool manufacturer guidelines for feed rate and spindle speed based on workpiece material and depth of cut.
