Accupro 14788326 Square End Mill 1 in 2 Flute Solid Carbide

Product Description

The ACCUPRO 14788326 is a solid carbide square end mill designed for precise milling operations in metal, composites, and engineered materials. With a 1.0000-inch mill diameter and a 1.7500-inch length of cut, this two-flute tool delivers efficient chip evacuation and clean shoulder profiles. The helical flute geometry reduces cutting forces and supports smoother finishes at higher feed rates. Centercutting capability allows direct plunge entry without a pre-drilled pilot hole, expanding its range of use in slotting, profiling, and pocket milling applications. Installed by machinists and toolroom professionals on CNC and manual milling machines.

This end mill suits general-purpose and production milling in ferrous and non-ferrous materials. The 1.0000-inch cylindrical shank fits standard ER and side-lock toolholders common on vertical machining centers and manual knee mills. With a 4-inch overall length, it provides adequate reach for most standard depth applications without sacrificing rigidity. No extended reach and no chipbreaker geometry keep the design straightforward for conventional roughing and finishing passes at typical cutting parameters.

Key Features

• Solid carbide construction for rigidity and wear resistance in demanding cuts
• 2-flute helical design promotes chip clearance in slotting and pocket operations
• Centercutting capable — supports direct plunge entry without pilot hole
• 1.0000-inch mill diameter with matching 1.0000-inch cylindrical shank
• 1.7500-inch length of cut accommodates standard depth-of-cut requirements
• 4-inch overall length maintains tool rigidity at typical reach

Compatibility

Designed as an OEM-style replacement or direct-use solid carbide square end mill for standard 1-inch toolholders on CNC vertical machining centers and manual milling machines.

Installation Notes

Installation is performed by a qualified machinist or toolroom technician. Always power down and lock out the spindle before changing tooling. Seat the shank fully into the toolholder and torque the retention mechanism to the toolholder manufacturer specification. Verify runout with a dial indicator before commencing cuts to protect both the tool and the workpiece.
