Accupro 12184054 Ball End Mill 0.75in 2 Flute Solid Carbide

Product Description

The ACCUPRO 12184054 is a solid carbide ball end mill designed for precision milling operations in metalworking and machining applications. It features a 0.75 inch diameter cutting head with a 1.5 inch length of cut and a 4 inch overall length, making it well suited for profiling, contouring, and finishing passes on hardened and abrasive materials. The AlTiN coating provides high heat resistance and extended tool life in demanding cutting conditions. With a 40-degree helix angle and micrograin carbide construction, this single-end mill delivers consistent chip evacuation and surface finish quality in production environments.

This ball end mill is used in CNC machining centers and manual mills for 3D contouring, slotting, and profiling operations on ferrous metals, hardened steels, and high-temperature alloys. The right-hand cutting direction and spiral flute geometry make it appropriate for conventional and climb milling strategies. It is commonly installed by machinists and CNC operators in job shop and production machine shop settings.

Key Features

• 0.75 inch mill diameter with 1.5 inch length of cut for moderate-depth profiling
• Solid micrograin carbide construction for rigidity and wear resistance
• AlTiN coating for improved heat resistance and tool life in hard and abrasive materials
• 40-degree helix angle promotes efficient chip evacuation and reduced cutting forces
• Single-end, right-hand cut and right-hand spiral flute geometry
• 0.75 inch shank diameter for secure tool holding in standard collets and end mill holders

Compatibility

Designed for use in CNC machining centers and manual mills accepting a 0.75 inch shank diameter. Compatible with standard ER, CAT, BT, and HSK tooling systems that accept 3/4 inch collets or end mill holders.

Installation Notes

Installation should be performed by a qualified machinist or CNC operator. Ensure the spindle is fully stopped and the machine is in a safe state before inserting or removing the tool. Verify shank engagement depth meets the toolholder manufacturer minimum grip length recommendation. Check runout with a dial indicator after installation to confirm proper seating before beginning a cut.
