Accupro 12182284 Square End Mill 3/8 in 3 Flute Solid Carbide

Product Description

The ACCUPRO 12182284 is a solid carbide square end mill designed for precision milling in metalworking and machining applications. Built from micrograin carbide with a TiCN (titanium carbonitride) finish, this tool delivers hardness and wear resistance for demanding cutting operations. It features a 3/8 inch cutting diameter, a 1 inch length of cut, and a 4 inch overall length. The 40-degree helix angle promotes smooth chip evacuation and reduces cutting forces. With three flutes and a spiral flute geometry, it is suited for high-efficiency slotting, profiling, and peripheral milling on ferrous and non-ferrous materials.

This end mill is intended for use in vertical machining centers, CNC mills, and manual knee mills across job shops, tool rooms, and production environments. The long-length configuration (1 inch LOC on a 4 inch OAL) provides added reach for deeper pockets and stepped features without sacrificing rigidity. It is centercutting, allowing plunge entry directly into the workpiece. The right-hand cut and right-hand flute configuration is the industry standard for conventional and climb milling setups.

Key Features

• Micrograin solid carbide construction for hardness and extended tool life
• TiCN coating improves surface hardness and reduces built-up edge on ferrous materials
• 40-degree helix angle for efficient chip evacuation and smooth cutting action
• Centercutting geometry allows direct plunge milling without a pre-drilled entry hole
• 3-flute design balances chip clearance and rigidity for slotting and profiling
• Long-length classification provides extended reach for deeper workpiece features

Compatibility

Designed as a standard 3/8 inch shank end mill compatible with ER collets, end mill holders, and hydraulic chucks sized for 3/8 inch shank tooling on CNC and manual milling machines.

Installation Notes

Installation should be performed by a qualified machinist. Ensure the spindle is fully stopped and machine power is off before mounting or removing the tool. Seat the shank to the recommended minimum engagement depth in the holder to maximize rigidity and minimize runout. Verify shank diameter tolerance compatibility with the holder to prevent slippage under load.
