Accupro 12182263 Square End Mill 3/4 Inch Solid Carbide

Product Description

The ACCUPRO 12182263 is a solid carbide square end mill designed for precision milling operations in metal cutting and machining applications. Built from micrograin solid carbide and finished with a titanium carbonitride (TiCN) coating, it delivers extended tool life and wear resistance in demanding cutting conditions. The cutter features a 3-flute spiral geometry with a 40-degree helix angle, right-hand cut, and right-hand flute direction. At 0.75 inches in diameter with a 3-inch length of cut and 6-inch overall length, this is an extra-long configuration suited for deep-cavity and extended-reach milling work. Centercutting capability allows direct plunge entry without a pre-drilled starting hole.

This end mill is used in CNC machining centers and manual mills for slotting, profiling, contouring, and pocket milling in ferrous and non-ferrous materials. The extra-long overall length of 6 inches makes it appropriate for mold work, deep-pocket machining, and applications where standard-length tooling cannot reach the workzone. It is installed and operated by machinists and CNC programmers working in job shops, tool rooms, and production machining environments.

Key Features

• Micrograin solid carbide construction for rigidity and heat resistance
• TiCN coating improves surface hardness and reduces friction at the cutting edge
• 40-degree helix angle promotes smooth chip evacuation and reduced cutting forces
• Centercutting design allows direct plunge milling without pre-drilling
• Extra-long 6-inch OAL with 3-inch length of cut for deep-reach applications
• Right-hand cut and right-hand flute direction for standard CNC spindle use

Compatibility

Designed as a standard 3/4-inch shank square end mill compatible with ER, side-lock, shrink-fit, and collet-style tool holders accepting a 0.75-inch shank diameter.

Installation Notes

Installation should be performed by a qualified machinist familiar with tool holder torque requirements and runout inspection procedures. Ensure the tool holder bore is clean and free of debris before seating the shank. Verify tool runout with a dial indicator before beginning a cut, as runout above acceptable limits will accelerate edge wear on carbide tooling. Always confirm spindle speed and feed rate parameters are set per the material and coating manufacturer guidelines before engaging the cut.
