Accupro 12179702 Square End Mill 3/16 in 3 Flute Carbide

Product Description

The ACCUPRO 12179702 is a solid carbide square end mill designed for precision milling in metalworking and machining applications. Built from micrograin carbide stock, it carries a zirconium nitride (ZrN) finish that increases surface hardness and reduces friction during cutting. The 3-flute spiral geometry with a 40-degree helix angle promotes chip evacuation and improves surface finish on ferrous and non-ferrous materials. At 3/16 inch in diameter with a 5/8 inch length of cut, this tool is well suited for slotting, profiling, and light pocket milling in tight workspaces. It is centercutting, allowing plunge entry without a pre-drilled hole.

This end mill fits standard CNC machining centers and manual milling machines configured for 3/16 inch collets or tool holders. Its regular-length configuration and 2 inch overall length make it appropriate for general-purpose work in production shops, tool rooms, and maintenance machining environments. Right-hand cut and right-hand flute orientation follow conventional setup for most vertical and horizontal milling spindles. Machinists working with aluminum, brass, mild steel, and similar materials will find this geometry effective for finishing passes and light roughing cuts at small diameters.

Key Features

• Solid micrograin carbide construction for rigidity and wear resistance at small diameters
• ZrN coating increases tool life and reduces built-up edge on non-ferrous materials
• 40-degree helix angle improves chip flow and reduces cutting forces
• Centercutting design allows direct plunge entry without pre-drilling
• 3-flute spiral geometry balances chip clearance with surface finish quality
• Right-hand cut and right-hand flute match standard spindle setups

Compatibility

Designed for use in CNC machining centers and manual mills accepting 3/16 inch round shank tooling with standard collets or end mill holders.

Installation Notes

Installation and tool changes should be performed with the machine spindle fully stopped and power isolated per shop lockout/tagout procedures. Seat the shank fully into the collet or holder and torque the retention hardware to the tool holder manufacturer specification. Verify runout with a dial indicator before taking the first cut. Tool projection beyond the holder should be minimized to reduce deflection at this small diameter.
