ACCENTRA AU-NTB623-NR nexTouch Capacitive Touchscreen Keypad Cylindrical Lock Augusta Lever

Product Description

The Accentra AU-NTB623-NR nexTouch keypad cylindrical lock integrates modern design with effective access control. This cylindrical lock utilizes a capacitive touchscreen and features the Augusta lever for easy operation. It is certified with ANSI/BHMA Grade 1 for superior durability and reliability. A keypad lockout feature enhances security by disabling the keypad after five incorrect attempts.

• Easy-to-use touch keypad for access control.
• Key-free operation reduces maintenance costs.
• ANSI/BHMA Grade 1 certified for long-lasting security.

Product Highlights

This lock provides a secure, reliable locking mechanism suitable for high-traffic areas.

Product Information

Standard Information

• Brand: Accentra (Formerly Yale)
• Finishes Available: 605 Bright Brass, 613E Dark Oxidized Satin Bronze, 626 Satin Chrome, BSP Black Suede Powder Coat

Technical Specifications

• Keyway: Accentra/Yale E1R (Para) Keyway, Schlage C Keyway
• Handing: Completely Reversible
• Lock Function: Touchscreen Keypad
• Fire Rating: UL Listed up to 3 Hours
• ADA Compliance: Meets ADA requirements – A117.1 Accessibility Code
• Power: Battery-operated with low power indicator or hard-wired option
• Reader Technology: Keypad only, no radio
• Strike: 4-7/8inch x 1-1/4inch ASA/ANSI strike
• Latch: 1/2inch throw, deadlocking
• Backset: 2-3/4inch
• Cylinder & Keys: 6-pin conventional, keyed different, with 2 keys
• Lever Design: AU (Augusta)
• Usage: Heavy Duty
• Door Thickness: 1-3/4inch
• Warranty: 3 Year Limited
