Abb XT2NU3125EFF000XXX Circuit Breaker 125A Xt

Product Description

The ABB XT2NU3125EFF000XXX is a circuit breaker from the Tmax XT series, designed to offer flexibility and reduce costs. Rated up to 250A and 600V, it handles both AC and DC current. It features breaking capacities up to 200kA, suitable for a range of applications. The Tmax XT series is globally certified with UL/CSA/IEC standards.

• Current Rating: 125 A
• Voltage Rating: 600 VAC
• Trip Unit: Electronic LS/I

Product Highlights

This ABB circuit breaker provides reliable circuit protection with electronic trip functionality and is suitable for various industrial applications.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: XT2NU3125EFF000XXX
• Country of Origin: United States

Technical Specifications

• Manufacturer Part Number: XT2NU3125EFF000XXX
• Manufacturer: ABB
• Product Series: Tmax XT
• Family Series: ABB Circuit Breakers, Tmax XT Series
• Description: CIRCUIT BREAKER 125A XT
• Poles: 3
• Current Rating: 125 A
• Max Voltage: 600 VAC
• Trip Unit: Electronic
• Electronic Trip Unit: LS/I
• Mounting: Panel
• Neutral Pole: No
• 100% Rated: No
• Terminal Type: Bolt-On
• Auxiliary Switch: Optional
• Shunt Trip: Optional
• Undervoltage Release: Optional
• UL Standard: 489
• Approvals: CSA, IEC, UL
• Gross Weight: 2.69 lbs
• Net Weight: 2.69 lbs
• Actuator Type: Toggle
• Alternate Mfr Part Number: 1SDA074904R1
• Breaking Capacity: 25 kA
• Connection: Bolt connection
• Construction: Built-in device fixed built-in technique
• IP Rating: IP20
• Mounting Orientation: Front side
• Number of Poles: 3 Pole
• Voltage Range: 240 to 600 V
