Abb TV10-8F-XV Contactor

Product Description

The ABB TV10-8F-XV is an electrical contactor designed for switching and controlling power circuits in commercial and industrial applications. Contactors in this class handle the repeated energizing and de-energizing of loads such as motors, lighting banks, and HVAC compressors. Licensed electricians and industrial maintenance technicians are the primary installers of this device. The unit weighs 0.45 pounds and measures 10.82 inches long by 7.81 inches wide by 4.96 inches tall, making it suitable for standard enclosure mounting in panel or control-cabinet installations.

The TV10-8F-XV is intended for use in electrical control panels where reliable load switching is required. Typical applications include motor control centers, HVAC equipment control circuits, and industrial automation panels. This contactor fits into commercial and light-industrial settings where space-efficient, dependable switching components are specified. Installation is performed by qualified electricians working within applicable NEC guidelines for control-circuit and motor-circuit applications.

Key Features

• Compact form factor at 10.82 x 7.81 x 4.96 inches for panel and enclosure mounting
• Lightweight construction at 0.45 pounds
• ABB industrial-grade contactor design for reliable load switching
• Suited for repeated make-and-break duty in motor and HVAC control circuits

Compatibility

Designed as an OEM-style replacement or direct-application contactor for commercial and industrial electrical control panels requiring a TV10-series ABB switching device.

Installation Notes

Installation must be performed by a licensed electrician in accordance with NEC requirements for the applicable circuit type. De-energize and lock out the panel or control cabinet completely before removing or installing the contactor. Verify coil voltage and load ratings match the circuit before energizing. Do not exceed the contactor's rated load capacity during operation.

Technical Specifications

• Length: 10.82 inches
• Width: 7.81 inches
• Height: 4.96 inches
• Weight: 0.45 pounds
• UPC: 72849414420

Standard Information

• Brand: ABB
• Manufacturer Part Number: TV10-8F-XV
