Abb TL240SCU 2 Circ 40A Indoor Surface

Product Description

The ABB TL240SCU main lug load center can function as a home's main panel or sub panel. Rated up to 60 degree/75 degree centigrade, it's suitable for use with service entrance equipment when installed according to electrical code. It features space for 2, 1" breakers, a 40 A bus ampere rating, and a surface enclosure.

• Main lug load centers can be used as a home's main panel or sub panel depending upon your preferences
• All ABB load centers are rated up to 60 degree/75 degree centigrade and is suitable for use with service entrance equipment when installed in accordance with electrical code
• The TL240SCU features space for 2, 1" breakers, a 40 A bus ampere rating, and a surface enclosure.

Product Highlights

The ABB TL240SCU load center is a reliable solution for distributing power in residential settings. It offers a 40A bus ampere rating and accommodates 2, 1" breakers.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: TL240SCU

Technical Specifications

• Category: Load Centers
• Grouping: Single Phase - USA
• 1" Space: 2
• Amperage: 40 A
• Circuit Breaker Style: Plug-In
• Device type: Main Lug
• Door: No
• Enclosure: Indoor
• Enclosure Type: Indoor, Surface Mount
• Factory Installed Ground Kit: No
• Feed: Either
• Input/Output Voltage: 120/240V ac
• Interrupting Capacity Rating: 65
• Load Center Type: Standard
• NEMA Rating: NEMA 1
• Phase: 1 Phase
• Service & Voltage: 1 Phase, 3 Wire, 120/240V ac
• Wires: 3 Wire
• UL/CUL Listing: UL
• Service Type: Single-Phase, Three-Wire
• Voltage Rating: 120/240 Vac
• IC Rating (Max): 65 kAIC
• Main Ampere Rating: 40 Amps
• Main Device Type: Main Lugs
• Feed Type: Top or Bottom
• Front Type: Surface Front
• Copper Bus: Yes
• 1 Pole, 1" Spaces: 2
• 2 Pole, 1" Spaces: 1
• 3 Pole, 1" Spaces: 0
• Door Included: No
• Agency Certification: UL
• Manufacturer: ABB
• Component: Load Center
