Abb THQD32200WL TQD 3-Pole 240V 10K IC 200 Amp

Product Description

The ABB THQD32200WL is a TQD 3-Pole 240V 10K IC 200 Amp thermal magnetic molded case circuit breaker and molded case switch. It comes complete with Cu/Al line and load lugs. It is suitable for reverse feed and has special HACR markings.

• Thermal magnetic molded case circuit breaker
• Complete with Cu/Al line and load lugs
• Suitable for reverse feed

Product Highlights

The ABB THQD32200WL circuit breaker is a reliable solution for circuit protection. It is suitable for various applications and ensures safety and performance.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: THQD32200WL

Technical Specifications

• Category: Thermal Magnetic
• Product Line: Thermal Magnetic
• GO Schedule: EF
• Trip Style: Non-Interchangeable
• Poles: 3
• Amperage: 200 A
• System Voltage: 240 Vac
• Frame Type: Q-Line
• 240 Vac Interrupting Rating: 10 KAIC
• Trip Function: LI
• Continuous Current Rated: Standard
• Suitable for Reverse Feed: Yes
• Lugs: TCAL25
• Long Time: Fixed
• Instantaneous: Fixed
• Current Metering: No
• Protective Relays: No
• Special Markings: HACR
• Wire Range (Cu/Al): (2) 1-300
• UL File #: E11592
