Abb TF30R 30A General Duty Fusible Safety Switch 3HP

Product Description

The ABB TF30R is a general duty fusible safety switch rated for 30 amps and 3 horsepower, designed for residential and light commercial electrical distribution applications. Built with a steel enclosure rated NEMA 3R, it provides protection against rain, sleet, and external ice formation, making it suitable for outdoor installations. The fusible design allows a licensed electrician to incorporate overcurrent protection directly at the disconnect point. This switch functions as a service entrance disconnect or branch circuit isolation device where a reliable, code-compliant shutoff is required.

The TF30R is suited for residential service entrances, light commercial panels, and outdoor disconnect applications where a weatherproof fusible switch is needed. The NEMA 3R enclosure makes it appropriate for installations exposed to the elements, such as rooftop HVAC equipment disconnects, exterior meter socket combinations, and utility-side service work. It is installed by licensed electricians working under NEC requirements for disconnecting means.

Key Features

• 30-amp fusible disconnect with 3HP motor load rating
• Steel NEMA 3R enclosure rated for outdoor, weatherproof installations
• General duty construction suited for residential and light commercial use
• Fusible design integrates overcurrent protection at the disconnect point
• Complies with NEC disconnecting means requirements

Compatibility

Designed as an OEM-style general duty fusible safety switch for residential and light commercial electrical service and branch circuit disconnect applications.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize the upstream power source and verify absence of voltage with a meter before handling any wiring connections. The NEMA 3R enclosure requires proper conduit entry sealing to maintain the weatherproof rating. Do not exceed the published ampere or horsepower ratings for the switch.

Technical Specifications

• Amperage Rating: 30 amps
• Horsepower Rating: 3 HP
• Switch Type: Fusible
• Duty Rating: General Duty
• Enclosure Material: Steel
• Enclosure Rating: NEMA 3R
• UPC: 783164209884

Standard Information

• Brand: ABB
• Manufacturer Part Number: TF30R
