ABB CSP10 CU SPLICE SLEEVE SLEEVE

Product Description

The Blackburn CSP10 is a compression splice designed for use with stranded copper conductors rated at one/ot AWG. This splice features a short barrel design for effective joining of wires. The unit is constructed from high conductivity seamless copper tubing and is tin-plated for resistance against corrosion.

• Designed for medium voltage applications up to thirty-five kV.
• Chamfered barrel for easy installation.
• Color-coded for die identification.

Product Highlights

Ideal for building and industrial applications, the Blackburn CSP10 provides reliable connections for stranded copper conductors in various environments.

Product Information

Standard Information

• Manufacturer: ABB - Installation Products
• UPC: 78378613208

Technical Specifications

• Application: Building, Confined Areas, Regular Duty and Industrial Applications
• Color: Pink
• Conductor Size: 1/0 AWG
• Conductor Type: Stranded Copper
• Finish: Tin Plated
• Length: 1-5/8 inches
• Manufacturer Part Number: CSP10
• Material: Copper
• Standards/Approvals: CSA Certified, Federal Specification 111.60-17, UL File No. E9809
• Type: Type CSP
• Voltage Rating: 35 kV
