Abb B938 Open Angle Connector 50 Pack

Product Description

The ABB B938 is an open angle connector designed for use with strut channel framing systems. It creates rigid 90-degree connections between intersecting strut members, allowing installers to build structural support frameworks for conduit, pipe, cable tray, and mechanical equipment. Fabricated for standard strut channel profiles, the B938 provides a bolt-together joint without requiring welding. Electricians, pipefitters, and mechanical contractors use this fitting as a core component in unistrut-style support assemblies in both new construction and retrofit applications.

Open angle connectors like the B938 are used in commercial and industrial installations where structural support frameworks must be assembled quickly and remain adjustable. Typical applications include overhead conduit runs, pipe support grids, equipment mounting frames, and seismic bracing configurations. The fitting is sold in a 50-piece pack, making it practical for larger jobs requiring consistent hardware throughout a support system.

Key Features

• Open angle design creates 90-degree rigid connections between strut channel members
• Bolt-together assembly eliminates welding in the field
• Compatible with standard strut channel framing profiles
• 50-piece pack quantity supports large-scale framing projects
• Consistent hardware across the pack ensures uniform joint quality throughout an installation

Compatibility

Designed as an OEM-style fitting for use with standard strut channel framing systems commonly found in commercial and industrial electrical, plumbing, and mechanical support applications.

Installation Notes

Installation is typically performed by licensed electricians, pipefitters, or mechanical contractors following applicable structural and electrical codes. De-energize any nearby electrical systems before working overhead. Use appropriately rated hardware and torque fasteners to the strut channel manufacturer specifications for the application load. Verify that the completed support assembly meets local building code and seismic requirements before putting the system into service.

Technical Specifications

• Package Quantity: 50 pieces per outer pack
• Package Weight: 40.63 pounds per 100 pieces
• Package Dimensions (L x W x H): 8.2 inches x 9.5 inches x 5.3 inches
• UPC: 78599175816

Standard Information

• Brand: ABB
• Manufacturer Part Number: B938
