Abb 653 Handy Box Extension Ring Outlet Box

Product Description

The ABB 653 is a handy box extension ring used to increase the depth or volume of a standard single-gang handy outlet box. This fitting mounts directly onto an existing handy box, creating additional wiring space for conductors, devices, and wire nuts. It is a common component in commercial and residential electrical rough-in work, installed by licensed electricians during new construction or renovation. The extension ring allows compliance with NEC box fill calculations when device count or conductor volume would otherwise exceed the base box capacity.

The ABB 653 extension ring is suited for use with standard single-gang handy boxes in light commercial and residential electrical installations. It is typically used in surface-mounted wiring applications where conduit-fed boxes are installed on walls or exposed structural surfaces. This part is installed during rough-in or when an existing box requires a volume upgrade to meet code.

Key Features

• Increases wiring volume of a standard single-gang handy outlet box
• Supports NEC box fill compliance by adding conductor capacity
• Designed for surface-mount conduit wiring applications
• Mounts directly to existing handy box for straightforward installation

Compatibility

Designed as an OEM-style extension for standard single-gang handy outlet boxes used in commercial and residential electrical conduit applications.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize the circuit and verify absence of voltage with a meter before working on or near the box. Secure all conductors and verify box fill calculations comply with NEC Article 314 after adding the extension. Do not exceed the conductor or device fill rating of the combined assembly.

Technical Specifications

• Product Type: Handy Box Extension Ring

Standard Information

• Brand: ABB
• Manufacturer Part Number: 653
