Abb 1SVR405621R1100 CR-U024DC2L Pluggable interface relay 2c/o 24VDC

Product Description

The ABB 1SVR405621R1100 CR-U024DC2L is a pluggable interface relay with 2c/o contacts, designed for various industrial applications. It operates at 24VDC and supports an output of 250V/10A. The relay features a built-in LED indicator for easy status monitoring. It is suitable for socket mounting and offers blade termination.

• Rated Control Supply Voltage: 24 V DC
• Output Signal: 250 V / 10 A
• Contact Form: DPDT

Product Highlights

The ABB CR-U series interface relay provides reliable switching with its silver-nickel alloy contacts and pluggable design.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: 1SVR405621R1100

Technical Specifications

• Category: Interface Relays & Optocouplers
• Function: Pluggable universal interface relay CR-U
• Rated Control Supply Voltage: 24 V DC
• Output Signal: 250 V / 10 A
• Output: 2 c/o (SPDT) contacts
• Contact material: silver-nickel alloy (AgNi)
• Product Main Type: CR-U
• Sub-Function: Relay with built in LED
• RoHS Status: Following EU Directive 2011/65/EU
• Object Classification Code: K
• ETIM 4: EC001437 - Switching relay
• ETIM 5.0: EC001437 - Switching relay
• ETIM 6.0: EC001437 - Switching relay
• ETIM 7: EC001437 - Switching relay
• eClass: 7.0 27371601
• Product Net Width: 35 mm
• Product Net Height: 54.4 mm
• Product Net Depth / Length: 35 mm
• Brand: ABB
• Manufacturer: ABB
• Coil Voltage: 24 VDC
• Contact Current Rating: 10 A
• Contact Form: DPDT
• Contact Voltage Rating: 300 VAC
• Control Voltage: 24 V
• Current Rating: 10 A
• Manufacturer Part Number: 1SVR405621R1100
• Mounting Type: Socket Mount
• Primary Type: Power Relays
• Relay Type: Interface
• Series: CR-U Series
• Termination: Blade
• Voltage Rating: 250 V
