A Y MCDONALD 72602T Pressure Reducing Valve

Product Description

The A Y MCDONALD 72602T is a pressure reducing valve designed for plumbing applications. It includes female National Pipe Thread (FNPT) union connections on both the inlet and outlet. The valve features a brass cap and complies with ANSI B1.20.1 standards.

• FNPT union connections on inlet and outlet.
• Maximum working pressure of 300 PSI.
• Reduced pressure range is 25 PSI to 75 PSI.

Product Highlights

This valve is suitable for various plumbing needs and ensures reliable performance in controlling water pressure.

Product Information

Standard Information

• Part Type: PRV
• Series: 72602T

Technical Specifications

• Inlet Connection: FNPT
• Outlet Connection: FNPT
• Inlet Connection Size: 1 1/4 inches
• Outlet Connection Size: 1 1/4 inches
• Material: NL Brass
• Cap Material: NL Brass
• Maximum Working Pressure: 300 PSI
• Reduced Pressure Range: 25 PSI to 75 PSI
• Factory Preset: 50 PSI
• Certification: ASSE 1003, ANSI/NSF 372, ANSI/NSF 61-G, CSA Standard B356
