80/20 Inc. 2080 Adjustable Hinge Polymer 4-hole

Product Description

The 80/20 INC. 2080 is a polymer adjustable hinge designed for use with modular framing and panel systems. It features a matte finish and a four-hole mounting pattern that allows for position adjustment during installation. Each leaf measures 1.125 inches wide by 2.5 inches tall, with an overall assembled width of 2.25 inches and a thickness of 0.77 inches. The pin is polycarbonate. At 0.095 pounds, this hinge is lightweight and suited for low-load door and access panel applications in aluminum extrusion-based assemblies. It ships as a single unit with a minimum order quantity of one.

This hinge is commonly used in Series 15 modular framing system builds, including enclosures, machine guards, workstation panels, and equipment access doors. It is appropriate for light-duty interior applications where a non-metallic, adjustable hinge point is needed. Industrial maintenance technicians, machine builders, and systems integrators are the typical installers. The adjustable design allows for minor door alignment corrections without full disassembly of the frame.

Key Features

• Polymer construction with polycarbonate pin for corrosion resistance in light-duty applications
• Adjustable hinge type allows door alignment correction after installation
• Four mounting holes per hinge for secure attachment to frame and door panels
• Matte finish reduces glare and blends with standard modular framing aesthetics
• Lightweight at 0.095 pounds, suitable for small access panels and enclosure doors
• Compatible with Series 15 modular framing profiles

Compatibility

Designed for use with 80/20 INC. Series 15 modular aluminum extrusion framing systems.

Installation Notes

Installation is typically performed by machine builders or maintenance technicians familiar with modular extrusion framing systems. Secure all fasteners through the four mounting holes on both the door leaf and frame leaf before adjusting final door position. Verify door alignment and hinge engagement before applying full load. This hinge is rated for light-duty use only and should not be used on heavy doors or in high-cycle applications beyond its designed load range.
