3M MNHU14-250DMIX Male Disconnect Terminal 16 to 14 AWG

Product Description

The 3M MNHU14-250DMIX is a fully insulated male disconnect terminal designed for use with 16 to 14 AWG conductors. This product is built from ETP/Electrolytic Copper and includes a heat shrink feature for enhanced moisture protection. Its 1/4 inch tab and butted barrel design ensure secure connections.

• Durable and moisture-resistant design
• Compatible with 16 to 14 AWG conductors
• 1/4 inch tab for easy installation

Product Highlights

This male disconnect terminal provides reliable performance in challenging environments.

Product Information

Standard Information

• Brand: 3M
• MPN: MNHU14-250DMIX

Technical Specifications

• Conductor Size: 16 to 14 AWG
• Tab Size: 1/4 inch
• Overall Length: 1.2 inches
• Temperature Rating: 221 degrees F
• Material: ETP/Electrolytic Copper
• Color: Blue
• Thickness: 0.032 inches
• Width of Pad: 0.25 inches
