3M 7100191410 Body Schutz Rubberized Undercoating 22 Fl Oz

Product Description

The 3M 7100191410 is a rubberized undercoating material designed for automotive body protection and sound deadening. It applies as a tough, fast-drying coating that bonds to bare or primed metal surfaces and cures to a medium-to-coarse, high-build texture. Once dry, the coating is fully paintable. The product ships with an assembled plastic dip tube that inserts directly into the can and connects to the 3M No Cleanup Applicator Gun 08801. Because the dip tube is disposable, no coating contacts the gun body, eliminating cleanup between uses.

This coating is used in automotive body shops, collision repair facilities, and fleet maintenance operations. It is suited for application on door skins, quarter panels, wheel wells, frame rails, trunk floors, and fenders. Installers working with conventional spray-on undercoating will find the high-coverage formula efficient: one 22 fl oz can covers up to 43 percent more surface area than a standard 32 fl oz conventional offering, reducing material cost per square foot on larger jobs.

Key Features

• Rubberized formula provides impact resistance and sound deadening on body panels and undercarriage surfaces
• Fast-drying and paintable when cured, allowing topcoat application without additional prep
• Medium-to-coarse, high-build texture for durable, OEM-style finish
• Disposable dip tube and nozzle system eliminates gun cleanup after use
• High-coverage yield: one 22 fl oz can covers up to 43 percent more area than conventional 32 fl oz products
• Compatible with 3M No Cleanup Applicator Gun 08801 for controlled, consistent application

Compatibility

Designed for use with the 3M No Cleanup Applicator Gun 08801. Suitable for application on metal body panels including door skins, quarter panels, wheel wells, frame rails, trunk floors, and fenders on passenger vehicles and light-duty trucks.

Installation Notes

Application is performed by automotive body technicians using the 3M No Cleanup Applicator Gun 08801; ensure the dip tube is fully seated before attaching to the gun. Apply in a well-ventilated area and follow all applicable safety data sheet guidance for solvent-based coatings, including appropriate respirator use. Allow the coating to dry fully before applying any topcoat or paint. Do not apply to surfaces that will be exposed to sustained standing water before the coating has cured completely.

Technical Specifications

• Container Size: 22 fl oz
• Texture: Medium to coarse, high build
• Finish When Dry: Paintable
• Coverage Advantage: Up to 43 percent more area than conventional 32 fl oz products
• Required Applicator: 3M No Cleanup Applicator Gun 08801
• Unit of Measure: Each
• Minimum Order Quantity: 6
• Weight: 2.1 pounds
• UPC: 00051135089644

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7100191410
