3M 7100164986 Male Wire Disconnect 22-18 Awg 0.187 in Tab

Product Description

The 3M 7100164986 is a male quick-disconnect terminal designed for reliable push-on wire connections in low-voltage wiring applications. Sized for 22 to 18 AWG conductors, the terminal features a 0.187 inch tab width that mates with standard 3/16 inch female disconnect receptacles. The partial vinyl insulation is colored red for quick identification of the 22-18 AWG wire range in accordance with common color-coding practice. RoHS 2011/65/EU compliant construction makes this terminal suitable for projects requiring restricted hazardous substance compliance. Licensed electricians, HVAC technicians, and control-panel wiring professionals use these terminals for control circuit terminations.

These male disconnect terminals are used in residential and light commercial wiring applications where quick-connect and quick-release terminations are required. Common install scenarios include HVAC control wiring, appliance wiring, automotive harness work, and panel sub-assembly wiring where 22-18 AWG conductors are used with 3/16 inch tab receptacles. They are sold in a package quantity of 100, making them practical for production or service shop use.

Key Features

• 0.187 inch tab width mates with standard 3/16 inch female disconnect receptacles
• Compatible with 22-18 AWG wire range
• Partial vinyl insulation for conductor protection at the terminal entry point
• Red insulation color for at-a-glance AWG range identification
• RoHS 2011/65/EU compliant for restricted hazardous substance applications
• Sold in a package of 100 terminals

Compatibility

Designed for use with 22-18 AWG conductors and standard 3/16 inch female quick-disconnect receptacles in control wiring and general electrical termination applications.

Installation Notes

Installation is performed by licensed electricians or qualified HVAC and controls technicians. De-energize the circuit completely before terminating or removing any disconnect terminals. Use a ratcheting or calibrated wire terminal crimper sized for insulated disconnects in the 22-18 AWG range to ensure a secure mechanical and electrical connection. Do not solder over the crimped connection, as this can create a stress point and degrade long-term reliability.
