3M 7100005959 Rubber Mastic Tape 2 Inches X 3 Ft 65 Mil

Product Description

The 3M 7100005959 is a black, 65 mil conformable rubber mastic tape engineered for electrical insulating and sealing applications. Built on an Ethylene Propylene Rubber (EPR) backing coated with a temperature-stable mastic adhesive, this self-fusing tape delivers a tight, void-free seal around irregular surfaces. It is rated for continuous operation up to 194 degrees F, making it suitable for demanding service environments. Electricians and electrical contractors reach for this tape when insulating and sealing bus bar connections, splices, and cable terminations where moisture intrusion and voltage stress are primary concerns.

This tape is used in commercial and industrial electrical work where conformable, high-build insulation is required. It is particularly well suited for splicing, padding, and sealing medium-voltage bus bar connections and cable splice joints. The self-fusing EPR construction conforms to irregular shapes and contours without air pockets, ensuring consistent insulation coverage across the entire splice area. Each roll measures 2 inches wide by 3 feet long and is sold individually with a minimum order quantity of 48 rolls per case.

Key Features

• 65 mil thick EPR backing provides substantial insulation build-up in fewer layers
• Self-fusing construction conforms to irregular surfaces and eliminates air voids
• Temperature-stable mastic adhesive maintains bond integrity up to 194 degrees F
• Suitable for insulating, padding, and sealing bus bar and splice connections
• Black color provides UV identification standard for electrical insulation applications
• Sold in cases of 48 rolls for job-site and stocking efficiency

Compatibility

Designed as an OEM-style insulating and sealing solution for bus bar connections, cable splices, and electrical termination applications requiring conformable high-build rubber mastic insulation.

Installation Notes

Installation should be performed by a licensed electrician following applicable NEC requirements. De-energize and lock out the circuit before applying tape to any splice or bus bar connection. Stretch the tape slightly during application to activate self-fusing and ensure full surface contact with no air gaps. Do not energize the circuit until the splice or termination is fully insulated and inspected per local code.

Technical Specifications

• Thickness: 65 mil
• Width: 2 inches
• Length: 3 feet
• Backing Material: Ethylene Propylene Rubber (EPR)
• Adhesive Type: Mastic
• Temperature Rating: 194 degrees F
• Color: Black
• Weight: 0.27 pounds
• Unit of Measure: Roll
• Minimum Order Quantity: 48 rolls per case
• UPC: 00054007434788

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7100005959
