3M 7010349245 Ring Terminal 12-10 Awg Crimp 50 Pack

Product Description

The 3M 7010349245 is a partially insulated circular ring terminal designed for reliable crimp connections on 12 to 10 AWG copper conductors. The terminal body is copper with a vinyl insulation sleeve in yellow, making wire gauge identification fast during installation. At 1.03 inches long and 0.38 inches wide, it fits a number 8 stud and delivers a secure mechanical and electrical connection. This terminal is suited for panel wiring, control circuits, and equipment terminations where a clean ring lug is required. Electricians and panel builders use these in residential, commercial, and light industrial applications.

This ring terminal is used wherever a conductor needs a fixed, bolted termination point at a number 8 stud. Typical applications include control panels, junction boxes, motor connections, and low-voltage wiring assemblies. The yellow color coding indicates compatibility with 12 to 10 AWG wire per standard color-code conventions used across the electrical trade. The partially insulated design leaves the barrel exposed for visual inspection of the crimp after installation while protecting the wire entry point.

Key Features

• Crimp connection type for fast, consistent terminations without soldering
• Copper contact material for excellent conductivity and corrosion resistance
• Vinyl insulation sleeve in yellow for 12 to 10 AWG wire gauge identification
• Fits number 8 stud size for broad panel and equipment compatibility
• UL Listed and CSA Certified with RoHS compliance for use in code-required installations
• Sold in a 50-piece package for bench stock and service inventory

Compatibility

Designed for use with 12 to 10 AWG conductors terminating at a number 8 stud. Suitable for standard crimp tooling compatible with partially insulated vinyl ring terminals in this wire range.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC requirements for the application. De-energize the circuit and verify zero voltage with a meter before terminating any conductors. Use a ratcheting crimp tool rated for insulated terminals in the 12 to 10 AWG range to ensure a full, consistent crimp. Inspect the barrel after crimping to confirm full wire insertion and no insulation pulled into the crimp zone.
