3M 7010290181 Silicon Carbide Unitized Wheel 3 in

Product Description

The 3M 7010290181 is a Silicon Carbide Unitized Wheel from the Standard Abrasives 500 Series, designed for light-pressure blending, finishing, and polishing on metallic and composite surfaces. Built with a soft, conformable non-woven construction, it delivers the finesse required for work within strict dimensional tolerances. The wheel measures 3 inches in diameter and weighs 2.309 pounds per unit. It is intended for use by machinists, fabricators, and metalworking tradespeople who need consistent, repeatable surface finishes without removing excessive base material.

This wheel is suited for flat and contoured workpieces in both ferrous and non-ferrous applications, including stainless steel, aluminum, exotic alloys, and titanium, as well as composite materials. It is a practical choice for deburring, blending weld seams, and final surface conditioning passes in fabrication shops and aerospace or industrial maintenance environments. The open web construction resists loading, extending usable abrasive life across production runs.

Key Features

• Soft density silicon carbide construction for fine surface blending and finishing
• Conforms to flat and contoured workpiece profiles, supporting close-tolerance work
• Compatible with ferrous metals, non-ferrous metals, exotic alloys, titanium, and composites
• Runs clockwise and counterclockwise for flexible tool and machine pairing
• Open web design resists loading for extended abrasive service life
• Attaches to a unitized wheel mandrel (sold separately)

Compatibility

Designed as an OEM-style replacement or standard production wheel for use with unitized wheel mandrels compatible with center-hole non-woven wheels in the 500 Series configuration.

Installation Notes

Installation and wheel changes should be performed by qualified personnel following the tool manufacturer's speed and mounting requirements. Always power down and disconnect the tool from its power source before mounting or removing the wheel. Confirm the spindle speed rating of the tool does not exceed the wheel's maximum rated RPM before operation. Appropriate eye protection and other PPE should be worn during use per applicable shop safety standards.

Technical Specifications

• Diameter: 3 inches
• Abrasive Material: Silicon Carbide
• Series: 500 Series
• Wheel Type: Unitized, Non-Woven
• Density: Soft
• Weight: 2.309 pounds
• Package Length: 7.31 inches
• Package Width: 4.19 inches
• Package Height: 3.88 inches
• Unit of Measure: Each
• Minimum Order Quantity: 10
• UPC: 051115353944

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010290181
