3M 7000120460 Roloc Disc Pad Assembly 1 Inch

Product Description

The 3M 7000120460 is a backup pad assembly designed to support Roloc 1 inch diameter abrasive discs in rotary tool applications. The pad features a 1/4-20 INT threaded mount, allowing direct attachment to tools equipped with a 1/4-20 EXT threaded shaft. The assembly includes a Roloc shank and adaptor, making it a complete, ready-to-install unit. Commonly installed by metalworkers, auto body technicians, fabricators, and maintenance professionals, this pad provides consistent backing support during surface prep, grinding, and finishing operations. Weighing 0.23 pounds, the lightweight construction minimizes user fatigue during extended use.

This disc pad assembly is suited for applications where 1 inch Roloc abrasive discs are used on die grinders, drill motors, or other rotary tools with compatible threaded shafts. Typical use cases include weld cleanup, surface conditioning, deburring, and blending on metal, fiberglass, and similar substrates. The integrated shank and adaptor eliminate the need for separate mounting hardware, streamlining tool changeovers in production and repair environments.

Key Features

• Supports 3M Roloc 1 inch diameter abrasive discs
• 1/4-20 INT thread mounts directly to tools with 1/4-20 EXT threaded shafts
• Includes Roloc shank and adaptor for complete, ready-to-use assembly
• Lightweight at 0.23 pounds for reduced operator fatigue
• Sold individually — each unit is one complete assembly

Compatibility

Designed for use with 3M Roloc 1 inch diameter abrasive discs. Compatible with rotary tools featuring a 1/4-20 EXT threaded shaft, including standard die grinders and drill motors configured for Roloc disc systems.

Installation Notes

Installation is performed by metalworking and finishing professionals using standard hand tools. Ensure the rotary tool is powered off and disconnected from any power source before attaching or removing the pad assembly. Thread the 1/4-20 INT end onto the tool shaft and hand-tighten securely before operating. Follow the tool and abrasive disc manufacturer guidelines for maximum RPM ratings to avoid disc separation during use.

Technical Specifications

• Disc Diameter: 1 inch
• Thread Type: 1/4-20 INT
• Compatible Shaft Thread: 1/4-20 EXT
• Weight: 0.23 pounds
• Unit of Measure: Each

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000120460
