Supco SHL190 thermostat limit control 190 degree F cut out temperature 25 amp 240vac

Product Description

The SUPCO SHL190 is a thermostat limit control designed for home heaters. This 3/4 inch (19mm) bimetal disc temperature control offers proven reliability, handling loads up to 25 Amps at 240VAC. It features a fixed cut-out temperature of 190 degrees F and a fixed cut-in temperature of 150 degrees F, with an open on rise switch action. This control is UL recognized and CSA approved, ensuring safety and performance.

• Thermostat Limit Control for Home Heater applications.
• 190 Degree F Cut Out Temperature and 150 Degree F Cut In Temperature.
• Handles electrical loads up to 25 Amps at 240VAC.

Product Highlights

Reliable 3/4 inch bimetal disc temperature control with 190°F cut-out and 25A/240VAC capacity.

Product Information

Standard Information

• Brand: SUPCO
• Manufacturer Part Number: SHL190
• Country of Origin: United States

Technical Specifications

• Manufacturer: Sealed Unit Parts Co., Inc
• MPN: SHL190
• Product Type: ELECTRONIC_COMPONENT
• Brand: Supco
• Cut Out Temperature: 190 Degree F
• Amperage: 25 Amp
• Voltage: 240Vac
• Control Type: 3/4 inch (19mm) Bimetal Disc
• Cut In Temperature: 150°F
• Differential: 40°F
• FLA @ 120VAC: 10A
• FLA @ 240VAC: 5A
• LRA @ 120VAC: 60A
• LRA @ 240VAC: 30A
• Pilot Duty: 125 VA
• RLA @ 120VAC / 240VAC: 25A
• Agency: UL®, CSA®
• Switch Action: Open on Rise
• Country of Origin: United States
• UPC: 687152141661
• Model Number: SHL190-40
• Wire Configuration: 2 Wire
• Electrical Ratings: 60T
• Switch Type: Snap Disc Auto Reset Limit Switch
• Included Accessory: Adapter Flange Plate
• Color: Black
• Series: SHL
