Supco SHF250 Fan Control Thermostat 25A 240VAC (1-Pack)

Product Description

Supco SHF250 is a fan control thermostat that closes on temperature rise and is designed for 240 VAC applications. The device uses a 3/4 in (19 mm) bimetal disc with welded construction and is UL recognized and CSA approved. It has a cut-in temperature of 250 F, a cut-out temperature of 220 F, and an electrical rating up to 25 A at 240 VAC, intended for HVAC and appliance fan control.

• 3/4 in (19 mm) bimetal disc; welded construction for current-carrying integrity; differential 30 F (cut-in 250 F, cut-out 220 F).
• Electrical rating up to 25 A at 240 VAC; SPST 60T12 contact; available in automatic and manual reset SPST or automatic reset SPDT configurations.
• UL recognized and CSA approved; intended for fan control in HVAC, air conditioners, heaters, refrigeration and appliance applications; includes mounting hardware.

Product Highlights

Fan limit thermostat, closes on rise; 240 VAC, 25 A rating; 250 F cut-in / 220 F cut-out; welded bimetal element; UL and CSA approvals.

Product Information

Standard Information

• Brand: SUPCO
• Manufacturer Part Number: SHF250
