Supco L175 Thermostat 60T11 Style 610072 3/4 inches (19 mm)

Product Description

Supco L175 is a 60T11-style L-Series bimetal disc SPST limit thermostat for temperature control in HVAC and appliance applications. The L175 uses a 3/4" (19 mm) bimetal disc with snap-action contacts that close on temperature fall and open on rise, with a 20°F differential (close 155°F, open 175°F). It features 1/4" quick-disconnect terminals, welded enclosed construction, auto-reset, and electrical ratings up to 25 A at 240 VAC with UL and CSA approvals.

• Snap-action SPST limit switch; closes on temperature fall and opens on rise (auto-reset)
• 3/4" (19 mm) bimetal disc sensing element; 20°F differential (close 155°F, open 175°F)
• Rated up to 25 A at 240 VAC; 1/4" quick-disconnect terminals; enclosed welded construction; UL and CSA

Product Highlights

L-Series 3/4" bimetal SPST limit thermostat, snap-action contacts, 25 A at 240 VAC, 1/4" quick-disconnect terminals, UL and CSA

Product Information

Standard Information

• Brand: SUPCO
• Manufacturer Part Number: L175
